The dislocation will want to change its shape if the force on a node is unbalanced. One way of allowing for this is to give the node a veloc- ity which is proportional to the force and inversely proportional to a drag coefficient, as in equation 3. Realism can be introduced by setting the drag coefficient for climb in response to a force component out of the glide plane to be much larger than that for glide, and allowing the coefficient for glide to vary with dislocation line direction between the edge and screw orientations. The effects of temperature can also be incorporated with a temperature-dependent drag coefficient and by probability-determined wait- ing times for thermally-activated processes section The other important issue is concerned with the density of nodes that define the dislocation line.

Computational efficiency requires the number of nodes in the system to be as small as possible, but accurate representation of the line shape is achieved if the nodal density is large. It is clear from Fig. Thus, the computer code has to be able to add and remove nodes in response to shape changes of disloca- tions during a simulation. Furthermore, segments on the same or different dis- locations can react to either annihilate or form segments with a different Burgers vector, and again nodes have to be added or removed.

With permission from Oxford University Press www. However, dislocation dynamics has more complexity. First, the response of a node depends on the direction of the force on it. Second, the number of atoms is constant in molecular dynamics, whereas the chang- ing number of nodes in dislocation dynamics requires that the inventory of nodes, nodal coordinates and Burgers vectors be updated after every time- step.

The choice of boundary conditions can also be problematic. Articles listed under Further Reading provide more detail. Dislocation dynamics has been applied to situations where either a few or many dislocations are involved. Interactions between two dislocations that are important in work hardening section As an example of the latter, Fig. The model has axes in , The initial dislocation arrangement shown in Fig. The large increase in dislocation density is apparent. The com- puting demands of this simulation were such that it used a parallelized code on computer clusters in which the number of processors increased from 16 to as the dislocations, and therefore number of nodes, multiplied.

The plots of stress and dislocation density versus strain for this simulation are described in section Humphreys CJ: Imaging of dislocations. Cherkaoui M, Capolungo L: Atomistic and continuum modeling of nanocrystalline materials: deforma- tion mechanisms and scale transition, , Springer.

Frederiksen SL, Jacobsen K: Density functional theory studies of screw dislocation core structures in bcc metals, Phil Mag , Guo ZX, editor: Multiscale materials modelling: fundamentals and applications, , Woodhead Publishing. Phillips R: Crystals, defects and microstructures: modeling across scales, , Cambridge University Press. Glide or conservative motion occurs when the dislocation moves in the surface which contains both its line and Burgers vector: a dislocation able to move in this way is glissile, one which cannot is sessile.

Climb or non-conservative motion occurs when the dislo- cation moves out of the glide surface, and thus normal to the Burgers vector. Glide of many dislocations results in slip, which is the most common manifesta- tion of plastic deformation in crystalline solids. It can be envisaged as sliding or successive displacement of one plane of atoms over another on so-called slip planes. Discrete blocks of crystal between two slip planes remain undis- torted as illustrated in Fig.

Further deformation occurs either by more movement on existing slip planes or by the formation of new slip planes. The slip planes and slip directions in a crystal have specific crystallographic forms. The slip planes are normally the planes with the highest density of atoms, i. Often, this direction is one in which the atoms are most closely spaced. In body-centered cubic metals the slip direction is the hi close-packed direction, but the slip plane is not well defined on a macro- scopic scale.

A slip plane and a slip direction in the plane constitute a slip system. These are readily detected if the surface is carefully polished before plastic deformation. Figure 3. Slip plane A characteristic shear stress is required for slip.
